The ESI SC-DX autosamplers were developed to solve the limitations
of autosamplers available to the analyst. Dual flowing rinse station
allows for the use of two different rinse solutions ensuring fast
wash-out of sample and minimal blank contamination. The
sample probe has no guide, thus eliminating a major cause of cross
contamination between samples.
Rapid, Accurate, Clean and Cost-Effective
The Linear/Polar motion - gives rapid sample changeover.
Auto zero feature after each sample ensures no missed vials.
Ultraclean dual-flowing rinse station does not use a peristaltic pump, ensuring no contamination from tubing.
Contamination from external sources eliminated with the optional HEPA filter cabinet.
No probe guide - eliminates a major cause of cross contamination.
Prices range from CHF 8500,- to CHF 15000,-.
Inert, Flexible and User Friendly
All fluoropolymer sample flow path construction - corrosion resistance.
All electrical components are encapsulation-sealed.
No metal or mechanical parts move over the samples vials.
Simple user set-up.
Multiple rack sizes can be utilized, for maximum flexibility.
Unique Features of the SC-Series Autosamplers
Unsurpassed Capacity
Maximum sample space made available on the sample platform
- up to 1260 samples in the case of the SC-14 ...
Smallest footprint / sample.
Dual Rinse Station
Allows the use of 2 rinse solutions.
Mimics best manual procedure.
Reduces contamination of blank solutions.
Ultra clean option.
-
Uses pressurized containers to supply rinse solutions.
-
No Contamination from Peristaltic Pump tubing.
Rapid
Simultaneous Linear / Polar motion ensures rapid movement between samples.
Sample to Rinse time ~3secs.
X-Y-Z speed user controllable.
Carriage is easily accessible for simple repair.
No Cross Contamination
Teflon-encapsulated carbon fibre sample arm & probe.
No probe guide, eliminates a major cause of sample cross contamination.
No metal or mechanical parts move over the sample platform.
SC-14 / SC-14T High Capacity Autosampler
The SC-14 provides unsurpassed sample capacity to ensure the longest
unattended operation for overnight runs. It can hold up to 14 racks of
Rack Type A or 24 racks of Rack Type B.
The SC-14 autosampler is available either as a bench-top unit or as a mobile autosampler with
integrated cart.
| Feature |
Benefit |
| High Capacity |
Unattended overnight runs |
| Linear / Polar Motion |
Faster Sampling |
| No Probe Guide |
Low Contamination |
| Mobile (option) |
Samples can be loaded in preparation area |
SC-2DX High Purity Autosampler
The SC-2DX provides a full-featured autosampler with a small footprint,
making it ideal for labs with minimal bench space. It can hold up to 2 Rack Type A
or 4 Rack Type B.
| Feature |
Benefit |
| Large / Small Vials accommodated |
All samples analyzed in a single run |
| Mechanism below sample tray |
Low contamination |
| No Probe Guide |
Low Contamination |
| Dual rinse station |
Mimics best manual procedure |
SC-E2DX and SC-E4DX Integrated Autosamplers
The first products to combine an autosampler with a sample tray mounted to the Element
2 ICP-MS, making a convenient interface ideal for either self-aspirating or pumping liquid samples.
| Feature |
Benefit |
| Large / Small Vials accommodated |
All samples analyzed in a single run |
| Mechanism below sample tray |
Low contamination |
| No Probe Guide |
Low Contamination |
| Dual rinse station |
Mimics best manual procedure |
| Fully Integrated with Element2 |
Easy maintenance &
fast rinse-out |
Other specifications
Dual Rinse Station:
- Optional Peristaltic Rinse Pump under the SC-14T
- Optional Pressurized Rinse, giving the lowest possible Rinse Contamination.
Mobile Station, SC-14 can be incorporated in a trolley.
Clean Enclosure options :
- HEPA filter enclosure.
- Protective dust cover.
FAST option - rapid sampling system, reduces analysis times 2x to 3x.
Encoder option, allowing direct reading of probe location at all times.
Power 100-240VAC, 50-60 Hz
Speed (Sample to Rinse): as low as ~3s
Communications
- RS-232 with USB and IEEE-488 options.
Software compatible with most ICP-OES / MS systems, please contact us for confirmation of your ICP Type.
|
|
|
| SC-E2 Integrated Autosampler |
|
|
SC-2DX Ultra Clean Autosampler
|
|
|
SC-8DX High Capacity Autosampler
|
|
|
|
SC-14 High Capacity Autosampler
|
|
|
sample #1 of SC-2DX rack plan
|
|
|
sample #2 of SC-2DX rack plan
|
|
|
SC-4DX autosampler with C6 rail
|
|
|
SC-E4DX with PC3 and FAST valve
|
|
|
SC-14 High Capacity Autosampler
|
|
|
sample SC-14 rack plan
|
|
